FTTH karp 4le adapterile SC-S või LC-D 80x80mm koos kaablijuhtimisega
picture picture picture

FTTH karp 4le adapterile SC-S või LC-D 80x80mm koos kaablijuhtimisega

Tootekood: EFBFTTH-BOX-IN-6
EAN: 4049759256616
Kaubamärk:
Ühik: tk
Laoseis: Tellimisel
Hind: 5,39 €
tk
 Lisa korvi

ARTICLE INFORMATION

• Suitable for drop cable to splice inside the box with pigtail inside
• Capable for the installation of different length of pre-terminated drop cable with LC and SC connectors, no splice process will be needed in this application
• The box is capable for 1/2/4F SC connections or 2/4F LC connections
• It can be Din rail mounted or wall mounted with screw
• The splice cassette is designed for 0.9mm buffer splice(40*1.2mm
• sleeves), bare fiber splice (40*0.5mm sleeves) or crimp splice
• It’s capable for drop cable between 2.0mm~5.0mm


PRODUCT FEATURES

  • Scope of application
  • Inside
  • Mounting
  • Wall mounting;DIN Rail
  • Possibility of mast mounting
  • False
  • Material
  • plastic
  • Colour
  • white
  • Cable entry without cable gland
  • 5 x 5 mm
  • Number of Fibres
  • 4
  • Type of Splice protection
  • Crimp or Thermo
  • Suitable for adapter
  • SC Simplex/LC Duplex/E2000®
  • Max. Assembly (Adapter)
  • 4
  • With Fiber overlength cassette
  • True
  • Hinged splice cassette
  • True
  • Holder for gas blocker
  • False
  • Cable sheath support
  • True
  • IP Protection
  • IP20
  • Foreign body and contact protection
  • Protection against medium-sized foreign bodies
  • Water protection
  • Without protection
  • Dimensions
  • 80 x 80 x 28 mm
  • Temperature Range
  • 0 – 50 °C
